Products

DESCRIPTION

Overview

Basic Info.

Model NO.	6213-Z
Valve Structure	Pilot Membrane Structure
Power Supply	AC, DC
Usage	Flow Control
Standard	GB
Application	Industrial Usage
Temperature Range (ºC)	NBR: -5~80, EPDM: -5~120, VITON: -10~150
Seal Material	NBR, EPDM, VITON
Protection Class	Explosion Proof
Voltage	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Orifice Size	13mm, 20mm, 25mm
Function	2 Way Normally Closed
Port Size	3/8′′, 1/2′′, 3/4′′, 1′′
Transport Package	Box, Carton, Pallet
Trademark	BRANDO
Origin	Ningbo, China
HS Code	8481804090
Production Capacity	10000 PCS Per Month

Product Description

Product Description

BRANDO is a professional solenoid valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. We focus to supply reliable, safe, zero leakage, and affordable solenoid valves to you. Such as general purpose type, explosion proof type, waterproof type, high temperature type, high pressure type, anti corrosive type, food safe type for your various industries for fluid control.Options for you: 1. Orifice Size: 1mm to 150mm2. Port Size: 1/8'', 1/4'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'', 2 1/2'', 3'', 4'', 5'', 6'', etc3. Connection Type: Female Threaded, Male Threaded, Flanged, Sub Base, etc4. Medium: Water, Air, Vaccum, Gas, Oil, Steam, Refrigerant, etc5. Body Material: Brass, Stainless Steel, Plastic, Aluminum Alloy, etc6. Seal Material: NBR, EPDM, VITON, PTFE, PEEK, Silicone, etc7. Operation: Direct Acting, Direct Lifting Diaphragm, Diaphragm Pilot Operated, Piston Pilot Operated8. Function: 2 Way Normally Closed, 2 Way Normally Open, 3 Way Normally Closed, 3 Way Normally Open9. Voltage: 12VDC 24VDC, 24VAC, 110VAC, 220VAC, etc10. Protection Class: IP65, IP67, Explosion Proof, etc

Technical Data

Model	Orifice Size(mm)	Port Size(Inch)	Working Pressure(bar)	Medium Temperature(ºC)	Body Material	Dimension
						A	F	K
6213	10	1/4''	0.3 to 10	NBR: -10 to +80EPDM: -30 to +120FKM: -30 to +150	BrassStainless Steel	50	32	90/85
	10	3/8''				50	32	90/85
	13	3/8''				65	41	91
	10	1/2''				50/55	32	90
	13	1/2''				58/65	41	91
	13	3/4''				58/69	41	94
	20	3/4''				83	60	115
	20	1''				83	60	115
	25	1''				83	60	115

Production Process

Payment & Delivery

FAQ

Question 1: What is a solenoid valve used for?Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.Question 2: How can you tell if your solenoid is bad?Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out coil, you need to troubleshoot the valve solenoids.Question 3: How do I choose a solenoid valve?Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, orifice size, temperature, pressure, voltage, response time and certification required for your application.
